8 port fast ethernet switch

-follow ieee802.3 ethernet and ieee802.3u fast ethernet protocol standards

-1.6gbps backplane bandwidth, eight 10/100mbps tx adaptive ports

-all 10m/100m ports support full-/half-duplex working mode

-1.19mpps packet forwarding rate, automatic mdi/mdi-x line sequence crossover

-automatic address learning and aging, 2k mac address space

  • 1
  • 2
  • 3
  • 4
1
2
3
4
ns108

product parameters

product hardware specifications

product model

ns108
standard protocol ieee 802.3 10base-t、ieee 802.3u 100base-tx
network medium

10base-t: cat3 or above utp

100base-tx: cat5 or above utp

port 8*10/100m rj45 lan port
forwarding rate 10/100mbps
backplane bandwidth

1.6gbps

mac address table 2k
size 130*70*26mm(l*w*h)
led display 10/100mbps(link/act)、power
power dc 9v/500ma
working environment

operating temperature: 0°c ~ 40°c

storage temperature: -20°c ~ 70°c

operating humidity: 10% ~ 90%, rh  non-condensing

storage humidity: 5% ~ 90%, rh non-condensing
