-follow ieee802.3, ieee802.3u, ieee802.3z, ieee802.3x ethernet protocol standards
-32gbps backplane bandwidth, 16x10/100/1000mbps adaptive ports, to meet multi-scenario use
-each port supports full-/half-duplex working mode
-adapt to desktop and rack weak current boxes, unrestricted deployment
-automatic address learning and aging, 8k mac address table
-8-core metal shielded port, stable transmission without packet loss
| product model | ns1316c |
| standard protocol | ieee802.3,ieee802.3u,ieee802.3z,ieee802.3x |
| port |
16*10/100/1000m rj45 lan port |
| rom | 4m |
| forwarding rate | 10/100/1000mbps |
| store and forward | support |
| backplane bandwidth | 32g |
| mac address table | 8k |
| size | 200mm（l）×118mm（w）×44mm（h） |
| led display | pwr、16lan link |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
| power | 12v/1a |
| weight | 700g |
