-48gbps backplane bandwidth
-35.71mpps packet forwarding rate
-automatic mdi/mdi-x line sequence crossover
-8k mac address space
-crc to reduce error frames
|
product model |
nsd1324d |
| standard protocol | ieee 802.3 10base-t、ieee 802.3u 100base-tx、ieee 802.3ab 1000base-t |
| network medium |
10base-t: cat3 or above utp 100base-tx: cat5 or above utp 1000base-tx: cat5e or above utp |
| port | 24*10/100/1000m rj45 lan port |
| forwarding rate | 10/100/1000mbps |
| backplane bandwidth |
48gbps |
| mac address table | 8k |
| access method | csma/cd |
| size | 280 mm(l)* 173mm(w)* 44mm (h) |
| led display | 10/100mbps（link/act）、power |
| power | 100-240v ac，50/60hz |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
