provide 8 10/100/1000m poe ports 2 10/100/1000m uplink rj45 ports 1sfp uolink port. the ports can automatically detect and identify the power receiving devices that conform to the ieee 802.3at/af standard and supply power through the network cable, which can be used as power over ethernet devices; 2 gigabit uplink ports are designed to maximize port utilization.
|
product model |
ns2310gpe |
| standard protocol | ieee802.3af/at series protocol ieee802.3 ethernet media access control protocol ieee802.3i 10base-t ethernet ieee802.3u 100bast-tx fast ethernet ieee802.3ab 1000base-t gigabit ethernet ieee802.3x flow control |
| port |
8*10/100/1000m poe rj45 port 1* sfp uplink port |
| poe standard |
standard ieee802.3af/at protocol, the maximum power of a single port is 30w support overcurrent, overvoltage, short circuit protection support high power pd soft start support sequential boot support certified non-standard pd power receiving |
| forwarding mode | store and forward |
| forwarding rate | 10/100/1000mbps |
| access method | csma/cd |
| default working mode | normal switch mode |
| size | 180mm(l)* 100mm(w)* 27mm (h) |
| power | dc input 44v-57v 50/60hz |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
