provide 24fe poe ports 2ge uplink ports. the ports can automatically detect and identify the power receiving devices that conform to the ieee 802.3at/af standard and supply power to them through the network cable, which can be used as a power over ethernet devices; support poe watchdog function,support ordinary switch/250m transmission
product model |
ns1018gp |
standard protocol | ieee802.3af/at series protocol ieee802.3 ethernet media access control protocol ieee802.3i 10base-t ethernet ieee802.3u 100bast-tx fast ethernet ieee802.3ab 1000base-t gigabit ethernet ieee802.3x flow control |
port |
16*10/100m poe rj45 port |
poe standard |
standard ieee802.3af/at protocol, the maximum power of a single port is 30w, and the maximum power of the machine is 240w support overcurrent, overvoltage, short circuit protection support high power pd soft start support sequential boot support certified non-standard pd power receiving |
port lightning protection | common mode: 4kv
differential mode: 500v |
forwarding mode | store and forward |
basic functions | follow ieee802.3 ethernet and ieee802.3u fast ethernet protocol standards
support ieee802.3at/af standard, compatible with powered device (pd) supporting ieee802.3at/af support ieee802.3x full-duplex flow control and backpressure half-duplex flow control all ports have wire-speed forwarding capability supports self-learning and aging of mac addresses built-in 240w power supply |
forwarding rate | 10/100/1000mbps |
backplane bandwidth |
9.2gbps |
mac address table | 2k |
access method | csma/cd |
default working mode |
support ordinary switch/250m transmission |
size | 270mm(l)* 180mm(w)* 45mm (h) |
power | ac input 100v-250v 50/60hz |
working environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
