the one-input-two-output passive cascading poe extender, 350-meter surveillance network setup soultion; ip66-rated outdoor waterproof and dust-proof; dual-mode switching with just one-click; compatible with national standard poe switch.
model | ns3502p |
port |
1*10/100mbps rj45 port(poe input) 2*10/100mbps rj45 port(poe output) |
standards and protocols |
ieee802.3 ethernet media access control protocol ieee802.3i 10base-t ethernet ieee802.3u 100base-tx fast ethernet ieee802.3x flow control |
switch content | 0.6g |
mac address table | 2k |
power input |
support standard poe (12/36 or 45/78) ieee802.3af/at theoretical value 30w max |
network medium |
10base-t: 2 cat3 or above utp/stp (≤100m) 100base-t: 2 cat5 or above utp/stp (≤100m) 1000base-t: 2 cat6 or above utp/stp (≤250m) |
basic functions |
follow ieee802.3 ethernet and ieee802.3u fast ethernet protocol standards ai automatically detects and judges the strength of the signal, and turns on the ultra-distance transmission mode store and forward mac automatic learning and aging ieee802.3x full-duplex flow control and backpressure half-duplex flow control |
operating environment |
operating temperature: 0°c ~ 40°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
weight | 157g(not include packaging) |
bare machine size |
98mm*151mm*36mm |
packing size |
100mm*154mm*36mm |
